1" Mixing Valve with Pex Connections

  • $195.00

 Mixing Valve With 1" Pex Connections

Scald Protection Three-Way Mixing Valve


Product Specifications:

Maximum Hot Water Inlet Temp: 185 degrees

Cold inlet: 39 -85 degrees F

Hot inlet: 120 - 185 degrees F

Maximum pressure rating: 140 psi

Minimum required Temp Diff: between hot and mix : 18 degrees F

Minimum Flow:  1 GPM

The valve is designed to prevent the flow of water discharging from the mixed water outlet in the event of the failure of hot or cold supply.

ASSE 1070 listed

Valve is complete with check valve at both hot and cold inlets.

Can be used in hospitals, nursing homes, schools, etc,
